Printing modes


Color dye sublimation and monochrome retransfer technology.


Printing features


Double-sided printing, edge-to-edge printing, and a printing head with a resolution of 600 dpi.


Printing speed

• Single-sided printing (YMCK): 25 seconds per card - 144 cards per hour

• Double-sided printing (YMCKK): 37.5 seconds per card - 96 cards per hour

Card types

• Thickness of 0.76 mm, compliant with ISO CR80 - ISO 7810 PVC cards

• Composite PVC cards, PET-F cards, PET-G cards, polycarbonate cards, ABS cards.

Card capacity

• Input hopper: 250 cards

• Output hopper: 250 cards

Communication interfaces

• USB 2.0

• Ethernet TCP-IP 10BaseT and 100BaseT interfaces

Security

• RFID locking key

• Supports security lock (Kensington lock)

• Centralized locking system ensures the security of blank cards, ribbons, and film, preventing unauthorized access (optional)

• Encrypted security protocol ensures network security.

Encoding module

• Optional modules:

  • Magnetic stripe encoder ISO 7811

  • Dual-sided contact and contactless encoder

• Encoder connection: Built-in USB converter with one port

• Encoding options can be combined

• Pre-order required from the manufacturer.

Printing consumables

• High-definition transfer film: 500 prints per roll

• Holographic transfer film: 400 prints per roll

• YMCK: 500 prints per roll

• YMCKK: 400 prints per roll

• YMCKI (for smart cards and magnetic stripe cards): 400 prints per roll

• YMCKH ribbon (for non-PVC cards): 400 prints per roll

• YMCFK (UV ink): 400 prints per roll

Software platform

• Compatible with Windows® (32/64-bit): XP SP3, Vista, W7, W8, W10

• Comes with cardPresso XXS card design software for designing and modifying

  • Internal database (unlimited records)

  • Windows® (XP version and above)
