| Technical Specifications |
| Categories |
Details |
| GENERAL FEATURES |
- Color sublimation directly on the card and resin thermal transfer |
| - Rewritable card printing |
| - Single or double-sided print module |
| - Print resolution: |
| • In color and monochrome: 300x300 dpi & 300x600 dpi |
| • In monochrome: 300x1200 dpi |
| - Print optimization via color profile |
| - User interface: LED panel or LCD touch screen |
| PRINT SPEED |
- Single-sided (YMCKO): up to 280 cards/hour |
| - Double-sided (YMCKOK): 170 cards/hour |
| - Single-sided (YMCK) with lamination module: up to 215 cards/hour |
| CARD MANAGEMENT AND SPECIFICATIONS |
- Feeder capacity: 100 cards (0.76 mm – 30 mil) |
| - Hopper capacity: 100 cards (0.76 mm – 30 mil) |
| - Rear hopper capacity: 50 cards (0.76 mm – 30 mil) |
| - Card types: PVC cards, composite PVC cards, PET cards, ABS cards, and rewritable card |
| PORTS/CONNECTIVITY |
- USB (cable supplied) and Ethernet |
| - Wireless connection 802.11b/g on Wireless range |
| EVOLIS HIGH TRUST® RIBBONS |
- Automatic recognition and setup |
| - Ribbon cassettes for one-step installation or an EASY4PRO offer without cassette |
| - Ribbon types: |
| • YMCKO: 300 prints per roll |
| • YMCKOK: 200 prints per roll |
| • YMCKOO: 250 prints per roll |
| • Black monochrome: 2000 prints per roll |
| - List of ribbons available at www.evolis.com |
| LAMINATION (OPTION) |
- Standard single and double-sided |
| - Extensive laminate offering: patches (600 sides per roll) and varnishes (1,200 sides per roll), with or without hologram |
| - Alternate laminates (contact chip cut-out / magnetic stripe cut-out) |
| - List of laminates available at www.evolis.com |
| OPTIONS INTEGRATED ON SITE |
- Double-sided activation key |
| - 200-card feeder |
| - LCD touch screen |
| - Lamination module |
| SECURITY |
- Kensington® security lock |
| - Optional mechanical locking system |
| - Print head protection during maintenance or ribbon changes |
| - Erasing sensitive data from the printer memory |
| - Kineclipse® optional |
| - Optional internal scanner reader |
| ENCODING MODULES |
- Magnetic stripe encoder ISO 7811 |
| - Contact smartcard encoders |
| - Contactless smartcard encoders |
| - Dual smartcard encoders (contact / contactless) |
| - Options can be combined |
| - Factory or on-site installation |
| SOFTWARE |
- Printer management by Evolis Premium Suite for Windows, Mac, and Linux |
| - Evolis SDK available for easy product integration |
| - Supplied with cardPresso XXS for designing and printing badges |
| - OS compatibility list available at www.evolis.com |
| WARRANTY CONDITIONS |
- 1 year for the printer |
| - Optional extended warranty available |
